Application
Clean water without abrasive particles.
Domestic use, irrigation of gardens and farmland etc.
High head.
Suitable for water lifting, and distributing with small or medium pressure sets.
Installed in enclosed places, or at least protected against inclement weather.
Operating Conditions
Suction lift up to 9m.
Liquid temperature up to +40℃.
Ambient temperature up to +40℃.
Max. working pressure: 6 bar.
Motor
2-pole induction motor:50Hz.
Insulation Class: B.
Protection: IP 44.
Single-phase with capacitor and thermal overload protection.
Material
Pump body:Cast iron.
Motor bracket: Aluminum.
Impeller: Brass.
Shaft with rotor: Stainless steel or Cs45#.
Mechanical seal: Graphite to ceramic.
Copper winding.
100% Sufficient Capacity
Long cycle life as nominal
Good quality materials & assembling
